| Click Model For More Info | Valby GR-60 | Valby GR-60HD | GR75* | Valby GR-75 HD* | Valby GR 100 | Valby GR100 HD* | GR124HD* |
|---|---|---|---|---|---|---|---|
| Max. gripping width | 60 ½" | 60 5/8" | 74 ¾" | 74 3/4" | 98 7/8" | 98 7/8" | 123" |
| Min. opening | 3 ½" | 5 15/16" | 4"" | 5 ½" | 5 7/8" | 5 7/8" | 7" |
| Max. lifting capacity | 7700 lbs | 11,000 lbs | 11,000 lbs | 15,400 lbs lbs | 15,400 lbs | 22,000 lbs | 33,000 lb |
| Height. open | 38 3/8" | 38 3/8" | 38" | 34 ¼” | N/A | N/A | 62" |
| Height. closed | 20 ½" | 20 ½" | 26 ½" | 25 ½" | 31 1/8" | 32" | 41" |
| Width of wider claw | 15" | 15" | 18 ½" | 18 3/4" | 19 11/16" | 20 1/2" | 40" |
| Working pressure | 2900 psi | 2900 psi | 3625 psi | 2600 psi | 3660 psi | 3625 psi | 4351 psi |
| Jaw material | Hardox | Hardox | Hardox | Hardox | Hardox | Hardox | Hardox |
| Weight | 410 lb. | 540 lb. | 705 lb. | 830 lb. | 960 lb. | 1560 lb. | 3300 lb. |
| Recommended Rotator: | R6 | GV 12 | GV 12 | GV 12 | GV 12S | GV 12S | GV 12S |
VALBY® Grapples are manufactured in Europe to very high standards. We
have Log, Demolition, Waste, Sorting, Stone and Universal Grapples plus Clamshell
Buckets. They can be mounted on Excavators, Knucklebooms, Cranes, Backhoes,
Tractors and Skid Steers. Turn your base equipment into an Efficient Forestry
Machine!
VALBY® Log Grapple Specifications
| Click Model For More Info | GR28 | GR36 | GR44 | GR50 | GR50 HD | GR55 | GR55HD |
|---|---|---|---|---|---|---|---|
| Max. gripping width | 28" | 36" | 44" | 50 ¾" | 50 ¾" | 55" | 55" |
| Min. opening | 1 ¼ | 1 ½" | 2" | 3 ½" | 3 ½" | 1 ¼" | 1 ¼" |
| Max. lifting capacity | 13320 lbs | 2200 lbs | 2650 lbs | 3080 lbs | 3960 lbs | 4400 lbs | 5500 lbs |
| Height. open | 23 ½" | 33 ¾" | 27 ¾" | 26 ¼" | 26 ¼" | 30 ½" | 30 ½" |
| Height. closed | 12" | 17" | 18" | 19 ½" | 20" | 20" | 20" |
| Width of wider claw | 10" | 10" | 10" | 11" | 11 ½" | 11 ½" | 12 ½" |
| Working pressure | 2900psi | 2900 psi | 2900 psi | 2900 psi | 2900 psi | 2900 psi | 3625 psi |
| Jaw material | Raex 640 | Raex 640 | Raex 640 | Raex 640 | Hardox | Hardox | Hardox |
| Weight | 97 lb | 110 lb. | 165 lb. | 216 lb. | 304 lb. | 377 lbs. | 397 lbs. |
| Recommended Rotator: | R3 | R3 | R3 | R45 | R45 | R55 | R6 |
Click the model for more information.
LOG GRAPPLES
